| Características eléctricas | ||
| Tipo de Medición | RMS incluidos armónicos en un sistema de CA trifásico (3P, 3P N) | |
| Precisión de medición | voltaje | ±0,5% |
| Actual | ±0,5% | |
| Frecuencia | ±0,2% | |
| Factor de potencia | ±0,01 | |
| potencia activa | ±1% | |
| Potencia reactiva | ±1% | |
| poder aparente | ±1% | |
| Energía Activa | Clase 1/0,5 IEC 62053-21 Clase B/C EN50470-3 | |
| Energía reactiva | Clase 2 IEC 62053-23 | |
| Entrada y salida | |||
| Entrada | Actual
| Corriente nominal (Ib/Iref) | 10A |
| Corriente máxima (Imáx.) | 100A | ||
| Corriente mínima (Imin.) | 0.3A | ||
| Corriente inicial | 40mA | ||
| voltaje | Tensión nominal (Un) | 3*230/400 VCA | |
| Voltaje operativo | 80%~120% de la ONU | ||
| Salida | SDM630-P | 2 salidas de pulsos para imp/exp. energía | |
| SDM630-M/MT | 2 salidas de pulsos RS485 Modbus | ||
| SDM630-MB | 2 Salidas de Pulsos M-bus EN13757 | ||
| SDM630-2T | 2 Salidas de Pulsos RS485 Modbus 2 Tarifas (Doble Fuente de Alimentación) | ||
| SDM630-MB-2T | 2 Salidas de Pulsos M-bus EN13757 2 Tariffs (Dual Power Source) | ||
| SDM630-DI | 2 Salidas de Pulsos RS485 Modbus Entrada Digital | ||
| Comunicaciones Modbus RS485 | |
| Dirección de comunicación | 1~247 |
| Distancia de transmisión | 1000 m máximo |
| Velocidad de transmisión | 2400bps~115200bps |
| paridad | Ninguno (predeterminado), impar, par |
| Bits de parada | 1 o 2 |
| Tiempo de respuesta | <100 ms |
| Comunicaciones M-Bus EN13757-3 | |
| Dirección de comunicación | 1~250 |
| Distancia de transmisión | 1000 m máximo |
| Velocidad de baudios | 300bps~9600bps |
| paridad | Ninguno (predeterminado), impar, par |
| Bits de parada | 1 o 2 |
