Características eléctricas | ||
Tipo de Medición | RMS en sistema de CA monofásico (1P N) | |
Precisión de medición | Fuerza | 1% del rango máximo |
Energía Activa | IEC 62053-21 Clase 1.0/EN50470-1/3 Clase B | |
Energía reactiva | IEC62053-23 Clase 2, IEC 61557-12 Clase 2 | |
Frecuencia | 0,2% de frecuencia media | |
Actual | 0,5% del rango máximo | |
Voltaje | 0,5% del rango máximo | |
Factor de potencia | 1% de la unidad (0,01) |
Entrada y salida | |||
Aporte | Actual
| Corriente nominal (Ib/Iref) | 10A |
Corriente máxima (Imáx.) | 100A | ||
Corriente mínima (Imin.) | 0.5A | ||
Corriente inicial | 40mA | ||
Voltaje | Tensión nominal (Un) | 230V | |
Voltaje operativo | 80%~120% de la ONU | ||
Producción | SDM230-NMI | 2 salidas de pulsos RS485 Modbus | |
SDM230-NMI-2 | 2x RS485 Modbus |
Comunicaciones Modbus RS485 | |
Dirección de comunicación | 1~247 |
Distancia de transmisión | 1000 m máximo |
Velocidad de transmisión | 1200bps~38400bps |
Paridad | Ninguno (predeterminado), impar, par |
Bits de parada | 1 o 2 |
Tiempo de respuesta | <100mS |
Eastron Electronic Co., Ltd. headquartered in Jiaxing, China, near to Shanghai, Hangzhou, Jiangsu, is one of the leading high-tech manufacturer and supplier for electricity products and energy measurement solutions. Over the years, we have developed a rich range of electricity meters, sensors, communication modules and management systems.Custom Manufacturers of Medidor de exportación fotovoltaico/cero multifunción monofásico de carril DIN con actualización de datos de 50 mS.
Eastron keeps investing on the research and development of new technology and new products on electricity metering. We have energetic and innovative development teams in both China and UK,which help us keep the competitive edge in the market. The collaboration with leading universities and institutions also brings many cutting-edge technology into our products. To make sure the reliability of the products, Eastron has setup own professional lab that can performs EMC, LVD, accuracy and environment tests according to IEC, EN, GB, UL standards.
With more than 40 patented technologies on software, embedded software and hardware, Eastron has been awarded with “High-tech Enterprise” and “High-tech R&D Centre of Electricity Application”. Eastron strictly follows ISO 9001 Quality management system, and the production is approved by SGS according to MID standard.Suppliers and Factory of Medidor de exportación fotovoltaico/cero multifunción monofásico de carril DIN con actualización de datos de 50 mS
Creating value to and growing up with our partners is our mission. Eastron provides not only the high quality and innovative products, but also first-class service to all our customers. We have professional team for technical supports and aftersales services. We have provided products and services to more than 50 countries in Europe, Asia-Pacific, America, Middle East, and Africa. We pride ourselves on having long long-term partners globally that allows us to further our growth and bring our innovation and quality to the market.
