Características eléctricas | ||
Tipo de medida | RMS incluido en el sistema de CA monofásico | |
Precisión de medición | Fuerza | 1% |
Energía Activa | IEC 62053-22 Clase 0.5S, IEC 62053-21 Clase 1.0 | |
Energía reactiva | IEC62053-23 Clase 2, IEC 61557-12 Clase 2 | |
Frecuencia | ±0,2% | |
Actual | ±0,5% | |
Voltaje | ±0,5% | |
Factor de potencia | ±0,01 |
Entrada y salida | |||
Aporte | Actual | Corriente nominal | 5A |
Corriente máxima | 100A | ||
Corriente mínima | 0.25A | ||
Corriente inicial | 40mA | ||
Voltaje | Tensión nominal (Un) | 230V | |
Tensión operativa | 80% ~ 120% de la ONU | ||
Producción | SDM320C | Salida de pulsos RS485 Modbus | |
SDM320Y | Salida de pulsos RS485 Modbus | ||
SDM320Y-RF | Salida de pulsos RF | ||
SDM320C-DI | Salida de pulsos RS485 Modbus Entrada digital |
Comunicaciones Modbus RS485 | |
Dirección de comunicación | 1~247 |
Distancia de transmisión | 1000 m máximo |
Velocidad de baudios | 1200bps~9600bps |
Paridad | Ninguno (predeterminado), impar, par |
bits de parada | 1 o 2 |
