Eastron Smart X96-1A es un Analizador de Potencia Trifásico Montado en Panel Tipo CT RJ12 para Sistema de Clic Fácil. El medidor mide y muestra las características de los proveedores 1p2w, 3p4w y 3p3w, incluyendo voltaje, corriente, frecuencia, potencia, energía activa y reactiva, importada y exportada, armónicos, demanda máxima, etc.
El medidor admite autoalimentación desde cualquiera de las tres fases. La solución Concebida y diseñada en torno a un concepto "plug and play", sustituye la necesidad de cablear 6 cables secundarios individuales desde el sensor de corriente hasta el contador de energía, lo que ahorra hasta un 85% del tiempo de instalación y elimina también posibles errores de cableado.
|
Características electricas |
||
|
Tipo de medida |
RMS incluido en el sistema de CA monofásico |
|
|
Precisión de la medición |
Fuerza |
1% |
|
Energía activa |
IEC 62053-22 Clase 0.5S, IEC 62053-21 Clase 1.0 |
|
|
Energía reactiva |
IEC62053-23 Clase 2, IEC 61557-12 Clase 2 |
|
|
Frecuencia |
±0.2% |
|
|
Actual |
±0.5% |
|
|
Voltaje |
±0.5% |
|
|
Factor de potencia |
±0.01 |
|
|
De entrada y salida |
|||
|
Aporte |
Actual |
Corriente nominal |
5A |
|
Corriente maxima |
100A |
||
|
Corriente mínima |
0.25A |
||
|
Corriente de arranque |
40mA |
||
|
Voltaje |
Tensión nominal (Un) |
230V |
|
|
Voltaje operativo |
80% ~ 120% de la ONU |
||
|
Producción |
SDM320C |
Salida de pulso RS485 Modbus |
|
|
SDM320Y |
Salida de pulso RS485 Modbus |
||
|
SDM320Y-RF |
RF de salida de pulsos |
||
|
SDM320C-DI |
Salida de pulso RS485 Modbus Entrada digital |
||
|
Comunicaciones Modbus RS485 |
|
|
Dirección de comunicación |
1~247 |
|
Distancia de transmisión |
1000 m máximo |
|
Tasa de baudios |
1200bps~9600bps |
|
Paridad |
Ninguno (predeterminado), Impar, Par |
|
Bits de parada |
1 o 2 |
